Rock Mattresses

Rock Mattresses are a thin profile gabion and traditionally used in applications such as creek and channel linings where long term scour is an issue.

The confinement of appropriately sized stone within a mesh effectively increases the resistance of rock movement for a given flow condition and subsequently protects the underlying soil from scour. Cirtex® Rock Mattresses are typically supplied in plan area of 6m x 2m with varying product thicknesses ranging between 0.17m to 0.3m.

Like the Cirtex Gabions, the product is traditionally supplied as a zinc coated unit but also available with a PVC coating over the zinc where corrosion is likely to be an issue.

Additionally, Cirtex are able to supply product manufactured under a galfan wire coating process where the addition of aluminium to the zinc process can provide additional life to the wire in extremely aggressive environments.

Specifications

CODE
GRADE
ROLL SIZE

76528

Rock Mattress Galv

6m x 2m x 300mm

76531

Rock Mattress PVC

6m x 2m x 230mm

76529

Rock Mattress PVC

6m x 2m x 300mm

BENEFITS & FEATURES

  • A long term solution for aggressive scour applications
  • Flexible system can withstand ground movement
  • Uses locally available infill material
  • Can be anchored for greater stability
  • Inherent weight of product when installed can assist with slope stability
  • Design life up to 120 years
  • Supplied flat packed to be filled onsite

FAQs

What size rock do you need to fill Rock Mattresses?

What is the difference between PVC and Galv?

What is a galfan coating?

Do you need Geotextile and Geogrid?

Does the base need to be prepared/ stabilized before filled gabions are set in place?

Related Products

Gabions – Double Twist Wire Mesh Baskets

Gabions are a wire basket that are filled with rock and used for retaining structures and erosion protection applications.

DuraSlope – Reinforced Soil System

The DuraSlope system is for slopes up to 45º utilising primary structural geogrids for internal stability of the slope.

DuraMesh® – Reinforced Soil System

The DuraMesh system is a proven, engineered, reinforced soil system with a steel mesh facing for slopes up to 90°.

DuraGreen – Reinforced Soil System
