PaveSeal
PaveSeal is a nonwoven PET geotextile used in the repair and maintenance of pavement surfaces.
The addition of PaveSeal to the sealing process can help reduce or eliminate reflective cracking and provide a waterproof membrane between the old cracked surface and the new seal. The PaveSeal absorbs the tack coat providing a reinforced bituminous waterproof layer in the pavement. This waterproof layer prevents further deterioration of cracked pavements below and helps to reinforce the new surface.
The tack coat of 0.7 – 0.9 L/m² is applied followed by the PaveSeal on to the tack coat. Once the PaveSeal is laid another seal coat is applied, and the chip placed.
Frequently Asked Questions
Benefits & Features
- Wide 4m rolls for efficient installation
- PET continuous filament geotextile for minimum shrinkage
- Reduces reflective cracking
- Increases waterproofing performance
Specifications
Code
Product
Size
76757
PaveSeal AS240P
4m x 100m (400m2)
75758
PaveSeal AS280P
4m x 100m (400m2)
